MECOF Speedstyle Floor Type Milling Machine

Ex-works DAIMLER PROTOTYPE MANUFACTURING

CNC Milling Machine for Modelmaking 1997 model 16.000 x 1650 x 3000 mm (x-y-z), FIDIA M 30 Feed rate stepless (X-Y-Z) 20.000 mm/min Spindle taper HSK 50 A Spindle speed 15.000 min -1 Spindle motor 15 kW Equipped with: Milling head with 2 axes: SPAZIO 11 A +/- 110° / 2000 ° min -1 B +/- 400° Space required: 23.000 x 4960 x 6300 mm Total weight: ca. 35 ton Power installed: 190 kVA
